Kubernetes Ingress & Gateway API – Smart Traffic Control

What is Ingress?

Ingress is a Kubernetes API object that manages external access to services within a cluster, typically HTTP/HTTPS traffic.

Why It’s Used in Kubernetes?

Rather than exposing each service via a NodePort or LoadBalancer, Ingress allows you to define routing rules for multiple services using a single entry point.

Benefits:

• Centralized routing control

• SSL/TLS termination

• Path-based or host-based routing

• Reduced need for multiple external IPs

🧩 Basic Ingress YAML Example

apiVersion: networking.k8s.io/v1
kind: Ingress
metadata:
  name: web-ingress
  annotations:
    nginx.ingress.kubernetes.io/rewrite-target: /
spec:
  rules:
  - host: myapp.example.com
    http:
      paths:
      - path: /app1
        pathType: Prefix
        backend:
          service:
            name: app1-service
            port:
              number: 80

---

Role of Ingress Controller (e.g., NGINX, Traefik, HAProxy)

An Ingress Controller is a pod that reads Ingress resources and configures a load balancer (usually an HTTP proxy) accordingly.

🌐 Common Ingress Controllers:

• NGINX: Popular, widely adopted

• Traefik: Dynamic and supports modern routing features

• HAProxy: High-performance TCP/HTTP load balancer

🚀 Installation Example – NGINX

kubectl apply -f https://raw.githubusercontent.com/kubernetes/ingress-nginx/controller-v1.8.1/deploy/static/provider/cloud/deploy.yaml

Verify the ingress controller:

kubectl get pods -n ingress-nginx
kubectl get svc -n ingress-nginx

Look for the external IP:

kubectl get svc ingress-nginx-controller -n ingress-nginx

Deploy a Sample App (e.g., hello-world)

# hello-world-deployment.yaml
apiVersion: apps/v1
kind: Deployment
metadata:
  name: hello-world
  labels:
    app: hello-world
spec:
  replicas: 2
  selector:
    matchLabels:
      app: hello-world
  template:
    metadata:
      labels:
        app: hello-world
    spec:
      containers:
        - name: hello-world
          image: hashicorp/http-echo
          args:
            - "-text=Hello from Ingress"
          ports:
            - containerPort: 5678
---
apiVersion: v1
kind: Service
metadata:
  name: hello-world
spec:
  selector:
    app: hello-world
  ports:
    - port: 80
      targetPort: 5678

kubectl apply -f hello-world-deployment.yaml

Create Ingress Resource

# hello-world-ingress.yaml
apiVersion: networking.k8s.io/v1
kind: Ingress
metadata:
  name: hello-world-ingress
  annotations:
    nginx.ingress.kubernetes.io/rewrite-target: /
spec:
  ingressClassName: nginx
  rules:
    - host: yourdomain.com   # Change or use a local DNS like nip.io
      http:
        paths:
          - path: /
            pathType: Prefix
            backend:
              service:
                name: hello-world
                port:
                  number: 80

kubectl apply -f hello-world-ingress.yaml

Test the Ingress

If you’re using nip.io or /etc/hosts entry:

# Suppose External IP of ingress controller is 1.2.3.4
curl http://hello.1.2.3.4.nip.io

Or edit /etc/hosts:

1.2.3.4    yourdomain.com

Then:

curl http://yourdomain.com

---

What is Kubernetes Gateway API?

The Gateway API is a collection of Kubernetes Custom Resource Definitions (CRDs) that allow for fine-grained and extensible control over how traffic is routed into and within a cluster.

It is designed to:

• Enable separation of concerns between infrastructure and application teams.

• Support multi-tenant and multi-team environments.

• Provide vendor-neutral, portable API standards.

• Improve support for advanced traffic policies like header-based routing, retries, and traffic splitting.

Example: Gateway + HTTPRoute YAML

apiVersion: gateway.networking.k8s.io/v1
kind: GatewayClass
metadata:
  name: example-gatewayclass
spec:
  controllerName: nginx.org/gateway-controller

---
apiVersion: gateway.networking.k8s.io/v1
kind: Gateway
metadata:
  name: my-gateway
  namespace: infra
spec:
  gatewayClassName: example-gatewayclass
  listeners:
    - name: http
      protocol: HTTP
      port: 80
      allowedRoutes:
        namespaces:
          from: All

---
apiVersion: gateway.networking.k8s.io/v1
kind: HTTPRoute
metadata:
  name: my-route
  namespace: app
spec:
  parentRefs:
    - name: my-gateway
      namespace: infra
  rules:
    - matches:
        - path:
            type: PathPrefix
            value: /api
      backendRefs:
        - name: my-service
          port: 80

Ingress Resource vs Gateway API

Traffic Flow Comparison

Key Gateway API Components

GatewayClass – Defines Controller Implementation

Describes how Gateways should be instantiated across the cluster.

apiVersion: gateway.networking.k8s.io/v1beta1
kind: GatewayClass
metadata:
  name: example-nginx
spec:
  controllerName: k8s.io/nginx

Gateway – Defines the Listener & Network Entry Point

Specifies how external traffic enters the cluster (e.g., host, port, protocol).

apiVersion: gateway.networking.k8s.io/v1beta1
kind: Gateway
metadata:
  name: my-gateway
spec:
  gatewayClassName: example-nginx
  listeners:
  - name: http
    port: 80
    protocol: HTTP
    hostname: "example.com"

HTTPRoute – Define Routing Rules

Defines how requests are routed based on host/path.

apiVersion: gateway.networking.k8s.io/v1beta1
kind: HTTPRoute
metadata:
  name: my-route
spec:
  parentRefs:
  - name: my-gateway
  rules:
  - matches:
    - path:
        type: PathPrefix
        value: /app1
    backendRefs:
    - name: app1-service
      port: 80

TLSRoute – Define Encrypted Routing Rules (Optional)

apiVersion: gateway.networking.k8s.io/v1alpha2
kind: TLSRoute
metadata:
  name: tls-example
spec:
  parentRefs:
  - name: my-gateway
  rules:
  - backendRefs:
    - name: secure-app
      port: 443

---

Benefits of the Gateway API

🧩 Standardization

• Defines a clear spec across Kubernetes distros and vendors

• CRD-based design enables future extensibility

🔄 Cross-vendor Compatibility

• Decouples routing rules from the controller implementation

• Works with NGINX, Istio, Envoy, and more

👥 Separation of Concerns

• Infrastructure Teams: define GatewayClass and Gateway

• Application Teams: define HTTPRoute/TLSRoute per application

Production-Ready Controllers Supporting Gateway API

• NGINX Gateway

• Istio Gateway Controller

• Envoy Gateway

• Traefik Proxy

• HAProxy Kubernetes Gateway

🧠 Final Thoughts

• Ingress and Gateway API both route traffic, but Gateway API is more structured and extensible.

• Gateway API promotes a modular approach and is future-ready.

• Adoption is growing rapidly—especially in multi-tenant and enterprise-grade clusters.

• Learn both models to design flexible, scalable traffic routing architectures.

• Hands-on with YAMLs is key—try deploying each to understand their behavior.
